• ASME VIII Div 1 adsorbers with 20-year design life
• Switching valves rated for 5 million cycles
• PLC-controlled system with 7” full-color HMI
• Integrated oxygen analyzer for continuous purity monitoring
• Automatic standby mode based on pressure setpoints
• UL-listed control panel
• Cost Control: Generate oxygen on-site and avoid unpredictable price hikes from bulk suppliers.
• Uninterrupted Supply: Stay independent from delivery schedules and keep operations running, even in remote locations.
• Safer Operations: Eliminate the hazards of storing liquid oxygen tanks or high-pressure cylinders.
• Operational Flexibility: Scale production to match your process needs without restrictive contracts.
• Simplified Logistics: Reduce handling and transportation risks by producing oxygen where you use it.
Model | O2 SCFM (70ºF) | Inlet Air | Outlet O2 to Buffer Tank | Inlet O2 Flow Control | Outlet Oxygen to User | Length (inches) | Width (inches) | Height* (inches) | Weight* (lbs) | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
90% Purity | 93% Purity | 95% Purity | |||||||||
XGO215LS | 1.3 | 1.3 | 1.2 | ¾" | ½" | ½" | ½" | 35" | 26" | 81.5" | 711 |
XGO221LS | 1.7 | 1.7 | 1.5 | ¾" | ½" | ½" | ½" | 35" | 26" | 101.5" | 751 |
XGO226LS | 2.2 | 2.2 | 2 | ¾" | ½" | ½" | ½" | 35" | 26" | 81.5" | 1004 |
XGO232LS | 2.7 | 2.7 | 2.5 | ¾" | ½" | ½" | ½" | 35" | 26" | 97.5 | 1021 |
XGO241LS | 3.4 | 3.3 | 3.1 | ¾" | ½" | ½" | ½" | 35" | 30" | 81.5" | 1085 |
XGO247LS | 4.1 | 4 | 3.7 | ¾" | ½" | ½" | ½" | 35" | 30" | 101.5" | 1225 |
XGO259LS | 4.8 | 4.7 | 4.3 | 1" | ¾" | ½" | ½" | 35" | 30" | 81.5" | 1327 |
XGO268LS | 5.6 | 5.5 | 5.1 | 1" | ¾" | ½" | ½" | 35" | 30" | 92.5" | 1485 |
XGO276LS | 6.2 | 6.1 | 5.7 | 1" | ¾" | ½" | ½" | 35" | 37" | 90" | 1547 |
XGO288LS | 7.3 | 7.2 | 6.7 | 1" | ¾" | ½" | ½" | 35" | 37" | 97.5" | 1685 |
XGO2100LS | 8.6 | 8.4 | 7.8 | 1" | ¾" | ½" | ½" | 35" | 39" | 91.5" | 1916 |
XGO2118LS | 9.7 | 9.6 | 8.8 | 1" | ¾" | ½" | ½" | 35" | 39" | 100.5" | 2099 |
