The Value Plus Line of reciprocating compressors was engineered for industrial applications that require a gas or electric driven compressor that reaches pressures up to 150 psig. Each one of these industrial air compressors were designed to be vertically or horizontally mounted. With top quality bearings, cast iron cylinders, and vibration free compressor pumps, this compressor package was built to withstand all types of working conditions. A low initial purchase price provides great value to this reciprocating compressor.
- Large flywheel blades for maximum cooling
- Heavy duty inlet filter silencers for quiet operation and maximum particulate protection
- High profile fin design on cylinders and heads to ensure cool, vibration free operation and long life
Motor HP | Tank Capacity Gal. | Vertical PACKAGES | PUMP DETAIL | 125 PSI | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
|
| VP-SERIES MODEL | VOLTAGE | PART NUMBER |
Dimensions L × W × HInches
| Approx. | CYLINDERS | STAGES | RPM | CFM Del’y |
5* | 60 | VP5-40-6 | 230/1/60 | 317CDS8016 | 35 x 20 x 66 | 350 | 3 | 1 | 1220 | 11.4 |
*3600 RPM motor
Pump Model VP-55
VP-SERIES | 5 HP RECIPROCATING Compressors
Motor HP | Tank Capacity Gal. | Vertical PACKAGES | PUMP DETAIL | 125 PSI | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
|
| VP-SERIES MODEL | VOLTAGE | PART NUMBER |
Dimensions L × W × HInches
| Approx. | CYLINDERS | STAGES | RPM | CFM Del’y |
5 | 80 | VP5-55-8 | 230/1/60 | 318CDS8016 | 35 x 25 x 69 | 530 | 3 | 2 | 940 | 15.2 |
Pump Model VP-100
VP-SERIES | 7.5 HP RECIPROCATING Compressors
Motor HP | Tank Capacity Gal. | Vertical PACKAGES | PUMP DETAIL | 125 PSI | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
|
| VP-SERIES MODEL | VOLTAGE | PART NUMBER |
Dimensions L × W × HInches
| Approx. | CYLINDERS | STAGES | RPM | CFM Del’y |
7.5 | 80 | VP7-100-8 | 230/1/60 | 319CDS8016 | 40 x 25 x 71 | 720 | 4 | 2 | 570 | 22.7 |
Standard Warranty
The standard warranty covers parts and labor on the package components for one year and three years on the compressor pump. Each new Gardner Denver assembled unit has a 3 year warranty on the compressor pump against defects in materials of workmanship under normal use and service.
Premium Extended Warranty
Purchase a Premium Warranty Kit at the same time as your new Gardner Denver compressor package to receive extended warranty protection. This offer will double the coverage with an additional 3 years of warranty on the compressor pump (pumps & labor) providing 6 YEARS of worry-free coverage. The Premium Extended Warranty also provides an extra 12 months coverage on the package for a total of 24months.
Learn more about our reciprocating warranty options and how to register below:
