The MH Series Hydrapak is a pre-engineered, all-in-one hydraulic drive conditioning system designed to simplify hydraulic system design, installation, and operation in transport applications.



By integrating all critical components into a single compact unit, the Hydrapak eliminates the complexity of traditional reservoir-based systems while improving cooling performance, reducing weight, and minimizing maintenance requirements.

With flow rates up to 60 GPM, pressure ratings up to 5000 PSI, and durable stainless steel construction, the MH Series establishes the standard for hydraulic cooling systems used across modern transport equipment.

MH Series Hydrapak brochure cover

Country

Your request will be forwarded to the relevant individuals to assist with your request.
By clicking 'Send' you are authorizing Gardner Denver to contact you so that we may fulfill your request, as well as to communicate with you regarding our products and services.
Terms and Conditions
Privacy Policy

(* required fields)

Why It Matters

Hydraulic systems in transport applications must operate under demanding conditions, including:

  • High ambient temperatures
  • Continuous duty cycles
  • Limited frame rail space
  • Vibration and road shock



Traditional reservoir systems introduce unnecessary weight, complexity, and inefficiencies.



The MH Series Hydrapak solves these challenges by:

  • Delivering efficient hydraulic oil cooling in a compact footprint
  • Reducing system weight to increase payload capacity
  • Simplifying installation with pre-engineered configurations
  • Minimizing maintenance and potential failure points

 The result is a more efficient, reliable, and cost-effective hydraulic system.

What’s Inside: MH Series Models

MH1 & MH3 - Compact, Cost-Effective Solutions

Designed for lower horsepower applications:

  • Ideal for bobtail delivery trucks, fuel oil, propane, and utility vehicles
  • Efficient solution for product transfer pumps and light-duty systems



Specifications:

Model

Pressure (PSI)

Reservoir (Gal)

Flow (GPM)

Weight (lbs)

MH1

Up to 3000

2

20

49

MH3

Up to 3500

4

40

75



Product Photo Hydrapak mh V2

MH5 - High Flow, High Horsepower Performance

Designed for demanding hydraulic drive systems:

  • Supports high horsepower and continuous operation
  • Virtually maintenance-free design
  • Significant weight reduction compared to reservoirs



Key Specs

Model

Pressure (PSI)

Pressure (PSI)

Flow (GPM)

Weight (lbs)

MH5

Up to 4500

4.4

60

94

MHX - Ultra-Compact Next-Generation Design

The latest innovation in hydraulic cooling:

  • Only 8.9” wide (smallest in class)
  • No mounting bracket required
  • Flexible installation (driver or passenger side)
  • Easy maintenance access



Performance:

Model

Pressure (PSI)

Reservoir (Gal)

Flow (GPM)

HP Cooled

Weight (lbs)

MHX

Up to 5000

3.4

30

15.2

90

Product Photo Exterior front Mhx hydrapak V2

Reservoir vs Hydrapak: Key Differences

Feature

Traditional Reservoir System

MH Series Hydrapak

Weight

Up to 500 lbs

Less than 1/4 of reservoir weight

Cooling Efficiency

Limited airflow, heat retention

Maintains optimal oil temperature

Installation

Large, bulky, complex

Compact, pre-engineered system

Space Requirements

High frame rail demand

Minimal footprint

Environmental Risk

High risk of large oil spills

Reduced spill risk, environmentally friendly

System Design

Conventional

Integrated, modern system

Best Use Case

Large cylinder systems

Hydraulic motors and transport systems

Applications

The MH Series Hydrapak is used across a wide range of transport applications:

  • Crude oil transport
  • LPG and fuel delivery
  • Food and chemical transport
  • Bulk feed systems
  • Vacuum trucks
  • Water trucks
  • Utility and maintenance vehicles
  • Agriculture and mining equipment

 Designed for transport applications requiring reliable hydraulic performance and efficient cooling

Country

Your request will be forwarded to the relevant individuals to assist with your request.
By clicking 'Send' you are authorizing Gardner Denver to contact you so that we may fulfill your request, as well as to communicate with you regarding our products and services.
Terms and Conditions
Privacy Policy

(* required fields)

FAQs

A Hydrapak is a pre-engineered hydraulic cooling and conditioning system that integrates key components into a single compact unit, simplifying installation and improving system efficiency in transport applications.
