Ultima U55 - 160 kW

The Ultima oil-free screw air compressor series utilizes high efficiency low/high pressure dry screw airends. Each airend is individually driven by a motor that operates at 97% efficiency. The Ultima provides up to 70% turndown, delivers low off-load power consumption, maintains a 63-69 dBA noise performance and provides superior heat recovery.

Ultima™: A Groundbreaking Oil-Free PureAir Compressor

Ultima is a groundbreaking oil-free PureAir compressor. The unique design of this all-new compressor range from Gardner Denver utilizes both a low pressure and a high pressure dry screw airend—each airend individually driven by a variable speed, permanent magnet synchronous motor. This configuration offers exceptional efficiency compared to traditional oil-free technology.

Considering that energy consumption is the highest cost in the lifecycle of a compressor, the innovative design of Ultima allows us to deliver top-tier performance and unmatched efficiency. Remarkably, this is achieved within a footprint that is 37% smaller than a conventional two-stage oil-free compressor.

Ultima™ Delivers on Every Level

  • 100% oil and silicone-free
  • Designed for clean air in critical applications
  • Redefines efficiency for industrial compressors

Certified for Stringent Applications

Ultima compressors are 100% oil and silicone-free and meet ISO 8573-1 Class Zero (2010) standards, making them the ideal choice for the most stringent oil-free applications.

Recommended for use in:

  • Food and beverage industry
  • Pharmaceutical production
  • Electronics manufacturing
  • Automotive industry

For many industries air purity is a critical factor where even the smallest drop of oil risks contamination that can have effects such as:

  • Product spoilage
  • Production downtime
  • Damage to production equipment
  • Damage to brand reputation

Gardner Denver Enhances Ultima Oil-Free Range with Up to 50% Smaller Footprint

To load this content, approve your cookie preferences and allow the required cookies.

Gardner Denver Enhances Ultima Oil-Free Range with Up to 50% Smaller Footprint

Turn Waste Heat into Real Savings with E-max

Unlock hidden efficiency in your compressed air system with E-max heat recovery. This flyer reveals how up to 95% of compressor energy—normally wasted as heat—can be recovered and reused for space heating, hot water, or industrial processes. With a compact, turnkey solution, fast installation, and short payback time, E-max helps reduce energy costs and CO₂ footprint without impacting performance. Download the flyer to discover how easy it is to turn wasted energy into measurable savings.

Sustainable manufacturing icon with energy recovery arrow

Ultima™ – The Real Deal

A Revolution in Dry Screw Compressor Technology

What Makes the Ultima So Unique?

  • Most efficient two-stage dry screw compressor on the market
  • Uses independent low and high pressure dry screw airends
  • Each airend is driven by a variable-speed, permanent-magnet, water-cooled motor
  • Each motor operates at 97% efficiency (greater than IE4)
  • Large turndown range up to 70%
  • Lowest unloaded power consumption – only 8 kW
  • Significantly smaller footprint while maintaining 63–70 dBA noise performance
  • Available in water-cooled or air-cooled versions, both with heat recovery options

Superior Heat Recovery

  • All major components are water-cooled for more efficient performance
  • 94% of energy used is converted into heat; the closed-loop cooling system removes heat from motors, inverters, and airends
  • Ultima’s cooling system maximizes energy recovery from the entire package
  • Recovers 98% of the heat generated – approximately 12% more than standard systems
  • Outlet water temperatures up to 90°C
  • Heat recovery connections standard on water-cooled models, optional on air-cooled models

100% Oil-Free

  • Eliminates the risk of contamination

13% Higher Efficiency

The Digital Gearbox drives each airend individually, significantly improving performance across the full turndown range.

Lowest Unloaded Power

Ultima consumes only 8 kW when unloaded compared to over 20 kW in conventional machines.

Motor Efficiency

  • Permanent magnet synchronous motors deliver >97% efficiency
  • Compact design with maximum energy savings

Up to 70% Turndown

Accommodates large variations in demand without requiring an additional compressor – saving energy.

Ultra Quiet: 63 dBA

Fully enclosed, water-cooled design achieves industry-leading noise levels.

47% Smaller Footprint

Fits three Ultima machines in the space required for two conventional compressors.

98% Heat Recovery

Reclaims excess heat for use in other plant processes, improving overall efficiency.

Easy Installation

No ducting required for setup, simplifying installation and reducing costs.

Optimum Heat Recovery and Ultimate Cooling

Ultima uses a closed-loop water cooling system for all major components, with separate circuits for inter and after coolers. This ensures the highest possible heat recovery—approximately 10% more than comparable compressors. Air-cooling is also available.

Premium Productivity

Where most oil-free airends deteriorate quickly, Ultima uses German-engineered airends with a special coating that protects the compressor for life, maintaining maximum efficiency.

PureAir Silicone Free logo

PureAir Silicone Free

roughly 37% less floor space required

Roughly 37% less floor space required

Energy savings v traditional variable speed oil-free compressor

Graph shows energy savings v traditional variable speed oil-free compressor

Variable SPEED MACHINES, 50 & 60 HZ

MODEL

DRIVE MOTOR

NOMINAL PRESSURE

FAD*

COOLING METHOD

NOISE LEVEL**

WEIGHT

DIMENSIONS

L × W × H

HP

KW

PSIG

BAR

ACFM

M³/MIN

dB(A)

LBS

KG

IN. (MM)

U75

100

75

100

125

145

6.9

8.6

10

463

403

349

13.10

11.42

9.87

Air

64

7408

3360

127.7 × 54.9 × 78.4

(3244 × 1394 × 1992)

Water

63

6063

2750

85.4 × 54.9 × 78.4

(2168 × 1394 × 1992)

U90

125

90

100

125

145

6.9

8.6

10

568

506

449

16.09

14.32

12.73

Air

65

7408

3360

127.7 × 54.9 × 78.4

(3244 × 1394 × 1992)

Water

64

6063

2750

85.4 × 54.9 × 78.4

(2168 × 1394 × 1992)

U110

150

110

100

125

145

6.9

8.6

10

697

634

575

19.75

17.94

16.28

Air

65

7408

3360

127.7 × 54.9 × 78.4

(3244 × 1394 × 1992)

Water

64

6063

2750

85.4 × 54.9 × 78.4

(2168 × 1394 × 1992)

U132

180

132

100

125

145

6.9

8.6

10

818

763

701

23.16

21.60

19.86

Air

67

7408

3360

127.7 × 54.9 × 78.4

(3244 × 1394 × 1992)

Water

66

6063

2750

85.4 × 54.9 × 78.4

(2168 × 1394 × 1992)

U160

215

160

100

125

145

6.9

8.6

10

848

842

835

24.01

23.85

23.64

Air

70

7408

3360

127.7 × 54.9 × 78.4

(3244 × 1394 × 1992)

Water

69

6063

2750

85.4 × 54.9 × 78.4

(2168 × 1394 × 1992)

Data measured and stated in accordance with ISO1217 4th Edition Annex C and E at the following conditions:
Air Intake Pressure: 1 bar a/14.5 psi, Air Intake Temperature: 20°C/68°F, Humidity: 0% (dry)

Measured in free field conditions in accordance with the ISO 2151, tolerance ±3 dB(A)
